Qualities

Intelligent Hydraulics
A larger flow guarantees more efficiency, allowing wire rope reeling to proceed at a faster rate. Higher stability under simultaneous vibration-free luffing and lifting movements is achieved by the shuttered mode of independently regulated combined motions.

Two Pumps System for Intelligent Flow Distribution
Effective flow distribution is achieved by the electro-hydraulic control system, which is also energy-efficient, environmentally benign, and responsive to combined motions and minor impact shocks. Accurate management: Min, great inching performance. A single rope can move at a steady 1.2 m/min and min. With a slewing sound speed of 0.1°/s, a precise mm level raise is achieved. Smooth start and stop thanks to integrated slewing buffer control, which combines free swing, sequential braking, and a boost buffer.
Superior Performance Chassis
200,000 riding fatigue tests have validated the innovative structural frame's exceptional reliability.

Parameters

Operation

Counterweight - 7.5T

Max. Lifting Capacity - 55T

Max. Boom Length - 45m

Max. Jib Length - 16m

Max. Lifting Height - 61.5m

Max. Lifting Moment - 2009kN·m

Traveling

Available Districts - LHD area

Engine Model (Emission Standard) - DF Cummins ISLe340 30(Euro Ⅲ )

Max. Gradeability - 47%

Max. Traveling Speed - 90km/h

Wheel Formula - 8×4

Request for quote: +971525384269

Price: AED1200000
