Features

Efficient and Flexible
They are widely used in civil engineering because of their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operating efficiency, and small diameter and deep borehole construction.

Distinct Chassis
For rotary drilling rigs, a telescopic enormous widening chassis and roller type great diameter slewing bearings provide outstanding stability for drilling deep boreholes.
Solidly powered, imported large displacement EFI engine that is economical and energy-efficient. It makes use of real-time power distribution modification, power optimization control technology, fast reaction times, improved fuel efficiency, and energy savings.
Better Reliability
The mast has a box structure that is resistant to fatigue and torsion, the sixth-generation Kelly bar has a stronger block ring and better material, and the overall strength has grown.

Parameters

Main Chassis

Base Engine - Mitsubishi D06FRC-TAA

Engine Power - 147/2100kW/rpm

Emission Regulation - China Stage Ⅲ

Rotary Drive

Rated Speed - 5~35rpm

Rated Output Torque - 155kN·m

Pile

Max. Pile Diameter - 1500mm

Max. Pile Depth - 55/44m

Crowd System

Crowd Force - 155kN

Stroke - 4200mm

Line Pull - 160kN

Overall Machine

Overall Height - 18600mm

Operating Weight - 48T

Transport Width - 3100mm

Transport Height - 3265mm

Main Winch

Lifting Capacity - 160kN

Max. Line Speed - 80m/min

Rope Diameter - 26mm

Request for quote: +971525384269

Price: AED1581000
