ASPECTS:

Enhanced Chassis Strength

When compared to alternatives, the frame's superior materials minimise strain and stress by 51%.

Superior Suspension

Comfort, dependability, and increased uptime are guaranteed by a hydro-pneumatic system.

The front Gas and Oil Suspension

prolongs machine life and prevents malfunctions by lowering shock and vibration.

Complete Hydraulic Control

Control and safety are increased by effortless steering with emergency backup.

Sensible Controls

integrated display system with GPS and reversing camera, as well as a self-diagnosis module.

Parameters

Automatic/Manual - Automatic

Axle - 35+55+55(t)

Capacity (Struck/Heaped) - 50/61m³

Displacement - 16.72L

Engine Model - Weichai WP17G770E304

Gearbox Type   -

Left/Right Hand Drive - Left/Right

Load Weight - 90T

Lubrication System - Optional automatic lubrication

Max. Gradeability - >30%

Maximum Torque - 3000NM

Min. Turning Radius - 13000mm

Net Weight - 54T

Number/Type of Cylinders - 8/V shape,turbocharged

Size - 11165*5810*4850mm

Total Power - 925kW

Tyre - 18.00R33

Request for quote: +971525384269

Price: AED1467000
