Among the features are: Increased Chassis Strength
The improved materials used in the frame reduce stress and strain by 51% when compared to alternatives.
The Advanced Suspension
A hydropneumatic system ensures more dependability, comfort, and uptime.
By reducing shock and vibration, the oil and gas front suspension reduces malfunctions and increases machine life.
Fully Hydraulic Management
Comfortable driving with emergency backup improves control and safety.
Smart Controls
integrated self-diagnosis module, GPS, and reversing camera display system.

Parameters

Automatic/Manual - Automatic

Axle - 35+55+55(t)

Capacity (Struck/Heaped) - 50/61m³

Displacement - 16.72L

Engine Model - Weichai WP17G770E304

Gearbox Type   -

Left/Right Hand Drive - Left/Right

Load Weight - 90T

Lubrication System - Optional automatic lubrication

Max. Gradeability - >30%

Maximum Torque - 3000NM

Min. Turning Radius - 13000mm

Net Weight - 54T

Number/Type of Cylinders - 8/V shape,turbocharged

Size - 11165*5810*4850mm

Total Power - 925kW

Tyre - 18.00R33

Request for quote: +971525384269

Price: AED1467000
