Features

Successful and Flexible
In civil engineering, they are frequently used because of their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operational efficiency, and small diameter and deep borehole construction.

Different Chassis
Excellent stability is ensured when drilling deep boreholes using rotary drilling rigs equipped with telescopic enormous widening chassis and roller type great diameter slewing bearings.
economical and energy-efficient large displacement EFI engine that is imported and has a reliable power source. It uses real-time power distribution adjustment, power optimization control technology, fast reaction times, improved fuel efficiency, and energy savings.
Superior Reliability
A stronger block ring and better material are used in the sixth-generation Kelly bar, and the mast's box-shaped structure is more resilient to fatigue and torsion.

Parameters

Main Chassis

Base Engine - ISUZU 6HK1

Engine Power - 212/2000kW/rpm

Emission Regulation - China Stage III

Rotary Drive

Rated Speed - 5~34rpm

Rated Output Torque - 190kN·m

Pile

Max. Pile Diameter - 1800mm

Max. Pile Depth - 59/47m

Crowd System

Crowd Force - 180kN

Stroke - 4200mm

Line Pull - 180kN

Overall Machine

Overall Height - 21040mm

Operating Weight - 63T

Transport Width - 3210mm

Transport Height - 3560mm

Main Winch

Lifting Capacity  -185kN

Max. Line Speed - 75m/min

Rope Diameter - 28mm

Request for quote: +971525384269

Price: AED1362000
