Qualities

Intelligent Hydraulics
A larger flow guarantees more efficiency, allowing wire rope reeling to proceed at a faster rate. Higher stability under simultaneous vibration-free luffing and lifting movements is achieved by the shuttered mode of independently regulated combined motions.

Two Pumps System for Intelligent Flow Distribution
Effective flow distribution is achieved by the electro-hydraulic control system, which is also energy-efficient, environmentally benign, and responsive to combined motions and minor impact shocks. Accurate management: Min, great inching performance. A single rope can move at a steady 1.2 m/min and min. With a slewing sound speed of 0.1°/s, a precise mm level raise is achieved. Smooth start and stop thanks to integrated slewing buffer control, which combines free swing, sequential braking, and a boost buffer.
Superior Performance Chassis

200,000 riding fatigue tests have validated the innovative structural frame's exceptional reliability.

Parameters

Operation

Max. Lifting Capacity - 50T

Max. Lifting Height - 61m

Max. Lifting Moment - 2058kN·m

Max. Boom Length  44.5m

Max. Jib Length - 16m

Counterweight - 4.8T

Traveling

Engine Model (Emission Standard) = DF Cummins ISLe34030 (Euro Ⅲ)

Max. Traveling Speed - 85km/h

Wheel Formula - 8 × 4 × 4

Max. Gradeability - 45%

Available Districts - LHD area

Request for quote: +971525384269

Price: AED437000
