A top-performing machine for soil and rock layer work, the SANY SR285R-MIII Rotary Drilling Rig offers smooth, adjustable compound motion with torque and rotary speed control to meet various geological challenges. Its engines, crafted with the world’s leading suppliers, comply with Tier IV/III emission standards and deliver dependable, fuel-efficient power. The 15m extra-long stroke ensures fast crowding and pulling, making it ideal for long casing projects in sandy and gravelly environments. Real-time lock monitoring prevents damage, and constant wire rope tension extends service life. An HD touchscreen with 3ms refresh and smooth graphics provides an excellent user experience, while regular lubrication keeps maintenance easy.

Parameters

CFA Mode

• Crowd Force- /kN

• Stroke- 18300mm

• Overall Height- 33075mm

• Max. Pile Diameter- 1200mm

• Max. Pile Depth- 25.5m

• Operating Weight- 108T

• Line Pull- 1000kN

• Rated Speed- 5~24rpm

• Rated Output Torque- 285kN·m

Standard Mode

• Crowd Force- 260kN

• Stroke- 17100mm

• Overall Height- 25470mm

• Max. Pile Diameter- 2200mm

• Max. Pile Depth- 94/61m

• Operating Weight- 105T

• Line Pull- 355kN

• Rated Speed- 5~24rpm

• Rated Output Torque- 285kN·m

Main Chassis

• Base Engine- 6WG1

• Engine Power- 300/1800kW/rpm

• Emission Regulation- China Stage III

Low Headroom

• Crowd Force- 260kN

• Stroke- 4600mm

• Overall Height- 11655~13280mm

• Max. Pile Diameter- 2200mm

• Max. Pile Depth- 50m

• Operating Weight- 96T

• Line Pull- 355kN

• Rated Speed- 5~24rpm

• Rated Output Torque- 285kN·m

Overall Machine

• Transport Width- 3475mm

• Transport Height- 3625mm

Main Winch

• Lifting Capacity- 330kN

• Max. Line Speed- 70m/min

• Rope Diameter- 36mm

Price: 311000 AED

For More Information

Call us on: +971 525384269
