characteristics

Versatile and Effective
Their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operating efficiency, and small diameter and deep borehole construction make them popular in civil engineering.

Unique Chassis Type
For deep borehole construction, a telescopic huge widening chassis with a roller type large diameter slewing bearing is ideal.
Cost-effective and preserving energy
An imported big displacement EFI engine with a strong power output, power optimization control technology, real-time power distribution adjustment, quick reaction time, increased fuel economy, and greater energy efficiency.

Parameters

Main Chassis

Base Engine - Isuzu 6WG1

Engine Power - 300/1800kW/rpm

Emission Regulation - China Stage Ⅲ

Rotary Drive

Rated Speed - 5~24rpm

Rated Output Torque - 285kN·m

Pile

Max. Pile Diameter - 2300mm

Max. Pile Depth - 94/61m

Crowd System

Crowd Force - 260kN

Stroke - 6000mm

Line Pull - 335kN

Overall Machine

Overall Height - 25425mm

Operating Weight - 100T

Transport Width - 3490mm

Transport Height - 3690mm

Main Winch

Lifting Capacity - 330kN

Max. Line Speed - 72m/min

Rope Diameter - 36mm

Request for quote: +971525384269

Price: AED3328000
