Featured are:

Improved Chassis Strength

Compared to alternatives, the frame's superior materials minimise stress and strain by 51%.

The Advanced Suspension

A hydropneumatic system guarantees increased uptime, comfort, and dependability.

front Suspension for Oil and Gas

prevents malfunctions and prolongs machine life by lowering shock and vibration.

Completely Hydraulic Control

Control and safety are increased with effortless steering with emergency backup.

Astute Controls

Integrated display system with GPS and reversing camera, as well as self-diagnosis module.

Parameters

Automatic/Manual - Automatic

Axle - 35+55+55(t)

Capacity (Struck/Heaped) - 50/61m³

Displacement - 16.72L

Engine Model - Weichai WP17G770E304

Gearbox Type   -

Left/Right Hand Drive - Left/Right

Load Weight - 90T

Lubrication System - Optional automatic lubrication

Max. Gradeability - >30%

Maximum Torque - 3000NM

Min. Turning Radius - 13000mm

Net Weight - 54T

Number/Type of Cylinders - 8/V shape,turbocharged

Size - 11165*5810*4850mm

Total Power - 925kW

Tyre - 18.00R33

Request for quote: +971525384269

Price: AED1467000
