Features

Hydraulics with intelligence
Higher efficiency is ensured by larger flow, which permits wire rope reeling at a faster rate. Higher stability is achieved under simultaneous vibration-free lifting and luffing movements when shutted mode of independently controlled combined motions is used.

Two-Pump A System of Intelligent Flow Distribution
The electro-hydraulic control system achieves efficient flow distribution, is energy-efficient, ecologically benign, and responds quickly to combined motions and minor impact shocks. Accurate control: Outstanding performance inching, min. A single rope's steady speed is 1.2 meters per minute. A precise lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Integrated slewing buffer control: free swing technology, boost buffer, and sequential brakes for seamless starting and stopping.
High-performance chassis
High reliability was ensured by 200,000 cycling fatigue tests that validated the innovative structural structure.

Parameters

Operation

Max. Lifting Capacity - 50T

Max. Lifting Height - 61m

Max. Lifting Moment - 2058kN·m

Max. Boom Length  44.5m

Max. Jib Length - 16m

Counterweight - 4.8T

Traveling

Engine Model (Emission Standard) = DF Cummins ISLe34030 (Euro Ⅲ)

Max. Traveling Speed - 85km/h

Wheel Formula - 8 × 4 × 4

Max. Gradeability - 45%

Available Districts - LHD area

Request for quote: +971525384269

Price: AED437000
