Characteristic

Practical and Flexible
They are used extensively in civil engineering because of their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operating efficiency, and small diameter and deep borehole construction.

Different Chassis.
When drilling deep holes, rotary drilling rigs with telescopic enormous widening chassis and roller type big diameter slewing bearings provide outstanding stability.
robustly powered, imported, large displacement EFI engine that is economical and energy-efficient. It uses real-time power distribution modification, power optimization control technology, fast reaction times, improved fuel efficiency, and energy savings.

Excellent Reliability,
The sixth-generation Kelly bar has a stronger block ring and better material; the mast has a box structure that is resistant to fatigue and twisting; and the overall strength has risen.

Parameters

Main Chassis

Base Engine - ISUZU 6HK1

Engine Power - 212/2000kW/rpm

Emission Regulation - China Stage III

Rotary Drive

Rated Speed - 5~34rpm

Rated Output Torque - 190kN·m

Pile

Max. Pile Diameter - 1800mm

Max. Pile Depth - 59/47m

Crowd System

Crowd Force - 180kN

Stroke - 4200mm

Line Pull - 180kN

Overall Machine

Overall Height - 21040mm

Operating Weight - 63T

Transport Width - 3210mm

Transport Height - 3560mm

Main Winch

Lifting Capacity  -185kN

Max. Line Speed - 75m/min

Rope Diameter - 28mm

Request for quote: +971525384269

Price: AED1362000
